TPL

ER707-M2

Ean : 4895252500738

TP-Link Omada ER707-M2 router cablato 2.5 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet Nero

* Non viene rilasciata alcuna garanzia su eventuali errori delle descrizioni tecniche aggiuntive né sull'accuratezza delle foto, da intendersi come un mero servizio informativo
Connessione WAN
WAN Ethernet
Indicates whether the device features a dedicated Ethernet port for connecting to a wide area network (WAN).
Sì
SFP WAN
Indicates whether the device features a Small Form-factor Pluggable (SFP) port for Wide Area Network (WAN) connectivity.
Sì
Collegamento in rete
Standard di rete
The way in which the network is working
IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3q, IEEE 802.3u, IEEE 802.3x
Tipo di interfaccia Ethernet
The maximum data transfer rate supported by the network port, expressed in gigabits per second (e.g., 10 Gigabit Ethernet).
2.5 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet
Velocità trasferimento Ethernet LAN
The different speed levels of the Ethernet LAN connection.
10,100,1000,2500 Mbit/s
Capacità di trasmissione
The maximum volume of data that the device can process or transfer per second, measured in Gbit/s.
1,44 Gbit/s
Instradamento statico
Indicates whether the device allows the manual configuration of fixed paths for network traffic to specific destinations.
Sì
VLAN support
A Virtual Local Area Network (VLAN) consists of a group of computers and switches that can be physically distributed over different networks and buildings
Sì
Routing basato su criteri
Indicates whether the network switch can route traffic based on defined policies rather than just destination IP addresses.
Sì
Caratteristiche di gestione
Gestione web-based
Using a website/web application to manage something.
Sì
Universal Plug and Play (UPnP)
Indicates whether the device supports the automatic discovery and configuration of network services to allow seamless communication between devices on a local network.
Sì
Tasto reset
Indicates whether the device features a dedicated button to restore the unit to its original factory settings.
Sì
Connettività
Quantità porte Ethernet LAN (RJ-45)
Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet.
6
Numero di porte WAN/Ethernet LAN
The total number of available network ports used for Wide Area Network (WAN) and Local Area Network (LAN) connectivity.
6
Numero di porte WAN
The total number of Wide Area Network (WAN) ports available on the device for connecting to an external internet source.
1
Quantità di moduli SFP installati
An SFP ("small form-factor pluggable transceiver") is a transmitter/receiver which interfaces a network device motherboard (e.g. in a switch
1
Numero di USB
The total number of available Universal Serial Bus (USB) connection interfaces on the device.
1
Versione USB
Universal Serial Bus (USB) is an industry standard developed in the mid-1990s that defines the interface used for connection
2.0
Protocolli
Supporto DMZ
Indicates whether the device supports a Demilitarized Zone to allow external traffic to reach a specific internal host.
Sì
Cliente DHCP
Whether the product features a DHCP (Dynamic Host Configuration Protocol) to obtain IP addresses within a network.
Sì
Server DHCP
A server is a system which that responds to requests across a computer network to provide
Sì
Protocolli di rete supportati
Protocollo di rete riscontrato compatibile con questo prodotto
TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, SNMP
Sicurezza
Algoritmi di sicurezza supportati
Security algorithms are used to provide authentication
3DES, 128-bit AES, 192-bit AES, 256-bit AES, DES, MD5, SHA-1, SNMP, SNMPv2, SNMPv3
Filtraggio URL
Indicates whether the device can block access to specific websites based on their web addresses.
Sì
Prevenzione attacco ICMP
Indicates whether the device includes security mechanisms to protect against Internet Control Message Protocol (ICMP) flood attacks.
Sì
Lista di controllo accesso (ACL)
Indicates whether the device supports the definition of rules to filter network traffic and manage access permissions based on specific criteria.
Sì
NAT (Traduzione dell'indirizzo di rete)
Indicates whether the device can remap one IP address space into another while in transit.
Sì
Registro evento di sistema
Indicates whether the device maintains a record of internal system events and status changes for diagnostic purposes.
Sì
Quantità tunnerl VPN
The maximum number of simultaneous virtual private network connections that can be established.
66
Certificati di sicurezza
Conformità alla sostenibilità
Indicates whether the product complies with established environmental and sustainability standards.
Sì
Certificati di conformità
Indicates which regulatory, safety, and environmental standards the product complies with, as verified by recognized authorities or certification bodies.
CE, Federal Communications Commission (FCC), RoHS
Contenuto dell'imballo
Adattatore AC/DC
Indicates whether a power supply unit for connecting the device to an AC outlet is provided in the package.
Sì
Guida d'installazione rapida
Indicates whether a simplified, fast-start manual is included with the product.
Sì
Caratteristiche
Memoria flash
The total amount of non-volatile storage available for firmware or data, measured in MB.
128 MB
RAM installata
La capacità della memoria misurata in megabyte installata nell' hardware del sistema
1000 MB
Tipo di RAM
The type of internal memory such as RAM
DDR4
Sistema operativo Windows supportato
Windows vesions wich can be used with the device.
Windows 10, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows Vista, Windows XP
Compatibilità sistema operativo Mac
Mac operating systems e.g. OS X can be used with the device.
Sì
Sistema operativo Linux supportato
8 RT. Linux (9.4, 9.5), Red Hat Enterprise Linux 5.0 (supported with a pre-built package); SUSE Linux (10.3, 11.0, 11, 11.1, 11.2), Fedora (9, 9.0, 10, 10.0, 11.0, 11, 12, 12.0), Ubuntu (8.04, 8.04.1, 8.04.2, 8.10, 9.04, 9.10, 10.04), Debian (5.0, 5.0.1, 5.0.2, 5.0.3)
Sì
Design
Colore del prodotto
The colour e.g. red
Nero
Materiale della scocca
What the casing of the product is made of.
Acciaio
Montabile a parete
The product can be mounted on (attached to ) a wall.
Sì
Indicatori LED
The specific status lights available on the unit to provide visual feedback on its current state or connectivity (e.g., AC input, ACT, or Access).
LAN, Collegamento, Potenza, Velocità, Sistema, USB, WAN
Gestione energetica
Tipologia alimentazione
What the power source is.
dC
Voltaggio di uscita
The electrical potential difference delivered by the device, typically expressed in volts (e.g. 24-48).
12 V
Corrente d'uscita
The maximum electrical current that the device can provide to a connected load, measured in amperes (A).
1,5 A
Condizioni ambientali
Intervallo temperatura di funzionamento
The minimum and maximum temperatures at which the product can be safely operated.
0 - 40 °C
Intervallo di temperatura
The minimum and maximum temperatures at which the product can be safely stored.
-40 - 70 °C
Range di umidità di funzionamento
The range of relative humidity, expressed as a percentage, within which the device can function correctly without damage or performance loss.
10 - 90%
Umidità
The permissible range of relative humidity, expressed as a percentage, within which the product can be stored without damage.
5 - 90%
Dimensioni e peso
Larghezza
The measurement or extent of something from side to side.
226 mm
Profondità
The distance from the front to the back of something.
131 mm
Altezza
Altezza del prodotto
35 mm
Dati su imballaggio
Larghezza imballo
The distance from one side of the packaging to the other.
242 mm
Profondità imballo
The distance from the front to the back of the packaging.
323 mm
Altezza imballo
The distance from the top to the bottom of the packaging.
73 mm
Peso dell'imballo
Weight of the packaged product.
1,1 kg
TP-Link Omada ER707-M2. Standard di rete: IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3q, IEEE 802.3u, IEEE 802.3x, Tipo di interfaccia Ethernet: 2.5 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet, Velocità trasferimento Ethernet LAN: 10,100,1000,2500 Mbit/s. Protocolli di rete supportati: TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, SNMP. Algoritmi di sicurezza supportati: 3DES, 128-bit AES, 192-bit AES, 256-bit AES, DES, MD5, SHA-1, SNMP, SNMPv2, SNMPv3. Certificati di conformità: CE, Federal Communications Commission (FCC), RoHS. Memoria flash: 128 MB, RAM installata: 1000 MB, Tipo di RAM: DDR4
